Digital Desktop LCR Meter ET3502 Desktop High Precision Digital LCR Bridge +/-0.05% Accuracy, 10Hz~200KHz Measuring Range, 6 1/2 Digit Display Continuously 200-240V

ET3502 LCR digital bridges are high-precision component parameter analyzers making use of automatic balancing bridge principle, featuring 10 Hz~ 200 kHZ testing bandwidth, continuously adjustable frequency, 0.05% of basic measuring accuracy, automatic level control, list scanning and position counting, which can provide accurate and complete measurement and analysis for most components and materials, so it is wildly used in product R&D, component incoming inspection and online product sorting.0.05% basic accuracyA maximum of 200 time/s measuring speedFrequency measurement range of 10 Hz- 100KHz, 0.05% basic accuracy, 6 1/2 digit displayAmplitude of excitation signal 10 mV- 2 V adjustableInternal programmable DC bias voltageExternal additional DC bias voltage supportedAutomatic level adjustment of voltage or currentV,I testing signal monitoring10-point list scanning testing10-grade sorting and counting256 groups of correcting data for specified frequencies6 digit reading resolution7” LED display screen, Chinese and English interfacesUSB, Ethernet, RS232, GPIB, Handler interfaces

• +/-0.05% basic accuracy
• A maximum of 200 time/s measuring speed
• Frequency measurement range of ET3502：10Hz~200 kHZ
• Amplitude of excitation signal 10 mV- 2 V adjustable
• Internal programmable DC bias voltage
